Technical Specifications


Management

  • Managed via the web using the Cisco Meraki dashboard

  • Single pane-of-glass into managing wired and wireless networks

  • Zero-touch remote deployment (no staging needed)

  • Automatic firmware upgrades and security patches

  • Templates based multi-network management

  • Org-level two-factor authentication and single sign-on

  • Role based administration with change logging and alerts

Monitoring

  • Throughput, connectivity monitoring and email alerts

  • Detailed historical per-port and per-client usage statistics

  • Application usage statistics

  • Org-level change logs for compliance and change management

  • VPN tunnel and latency monitoring Network asset discovery and user identification

  • Periodic emails with key utilization metrics

  • Device performance and utilization reporting

  • Netflow support

  • Syslog integration

Cloud Diagnostics

  • Live remote packet capture

  • Real-time diagnostic and troubleshooting tools

  • Aggregated event logs with instant search

WAN Management

  • WAN link aggregation

  • Automatic Layer 3 failover (including VPN connections)

  • 3G / 4G USB modem failover

  • Application level (Layer 7) traffic analysis and shaping

  • Ability to choose WAN uplink based on traffic type

  • SD-WAN: Dual active VPN with policy based routing and dynamic path selection

  • Advanced Security Throughput: 200 Mbps (CryptoWall)

  • Advanced Security Throughput: 300 Mbps (CryptoWall X)

  • Maximum VPN Throughput: 100 Mbps

Network & Firewall

  • Stateful Firewall, 1:1 NAT, DMZ

  • Stateful Firewall Throughput: 250 Mbps (CryptoWall)

  • Stateful Firewall Throughput: 450 Mbps (CryptoWall X)

  • Maximum VPN Clients: 50

  • Identity-based policies

  • Auto VPN: Automated site-to-site (IPsec) VPN, for hub-and-spoke or mesh topologies

  • Client (IPsec L2TP) VPN

  • Multiple WAN IP, PPPoE, NAT

  • VLAN support and DHCP services

  • Static routing

  • User and device quarantine

Security

  • Content filtering (Webroot BrightCloud CIPA compliant URL database)

  • Web search filtering (including Google / Bing SafeSearch)

  • YouTube for Schools

  • Intrusion-prevention sensor (Cisco SNORT® based)

  • Advanced Malware Protection (AMP)

  • AMP Threat Grid

  • Geography based firewall rules (MaxMind Geo-IP database)

Integrated WiFi (wireless model only)

  • 1 x 802.11a/n/ac (5 GHz) radio

  • 1 x 802.11b/g/n (2.4 GHz) radio

  • Max data rate 1.2 Gbit/s (aggregate)

  • 2 x 2 MIMO with two spatial streams

  • 2 external dual-band dipole antennas (connector type: RP-SMA)

  • Antenna gain: 3.0 dBi @ 2.4 GHz, 3.5 dBi @ 5 GHz

  • WEP, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X authentication

  • FCC (US): 2.412-2.462 GHz, 5.150-5.250 GHz (UNII-1), 5.250-5.350 GHZ (UNII-2), 5.470- 5.725 GHz (UNII-2e), 5.725 -5.825 GHz (UNII-3)

Warranty

  • Full lifetime hardware warranty with next-day advanced replacement included.
